Strut system fittings offer modular and adaptable connection solutions for MEP support structures, enhancing installation efficiency and structural reliability.

Item code Hole Size Hole Spacing Channel Dimension Thickness
Single Post Base 9⁄16″ Diameter
14.3 mm		 13⁄16″ (20.6 mm) From End
1-7⁄8″ (47.6 mm) On Center		 1- 5⁄8″ x 1-21/32″
41.3 mm x 42.06mm		 1⁄4″
6.35 mm



Single post base application for steel post anchoring and structural support
Single post base installed to securely anchor steel posts to concrete foundations, providing stable structural support for fencing, railing, and construction applications.
